ATB-Ultimate Wheelchair

From $9995


At Lasher Sport, we always strive to improve on our designs. So after 3 years of riding the All Terrain Beast through tough terrain, and valuable feedback from current ATB users, we have come up with the ATB-Ultimate.

We based the ATB-Ultimate on a tough but exceptionally light weight magnesium frame. Then we added Frog Legs rear suspension with an adjustable center of gravity. The new ATB rides atop Vapor O2 wheels with 2.25″ wide mountain bike tires in the rear, and 12.5″ x 2.25″ front casters. But it doesn’t stop there… we have also included hydraulic disc brakes .

An adjustable angle mountain bike style push bar is also standard for when the trail gets difficult. Finally, side guards are standard on every ATB-Ultimate along with a custom slotted footplate with a toe guard. So basically, we’ve pretty much included almost every option possible on this chair, and made it standard. All in all, this chair rocks!

Download order form CHOOSE YOUR COLOR

Features

Standard Features

  • Magnesium Alloy frame
  • Aluminum billet components
  • Aluminum backrest plate
  • Mountain Bike Tires
  • Vapor O2 wheels
  • Adjustable angle push bar
  • 12.5″ x 2.25″ casters
  • Adjustable seating
  • Adjustable backrest
  • Custom Aluminum Side Guards
  • Hydraulic Disc Brakes
  • 5 Year warranty (frame only)

Optional Features

  • Custom powder coat color finish
  • Vinyl coated or natural fit handrims
  • Wheel and tire upgrades
  • Seat cushion upgrade
  • Calf Strap
  • Frame Bumper

Specs

ATB-Ultimate Specs
Base Price $9995
Frame Material Magnesium
Chair Weight 37 lbs
Upholstery Laminated Carbon Fabric
Back Adjustable Angle
Rear Wheels Sun Zero G
Rear Tires Mountain Bike
Brakes Hydraulic disc brakes
Push Bar Mountain bike style
Handrims Hard Anodized
Side Guards Custom Aluminum Plate
Footrest Slotted Foot Plate
with Toe Guard
Seat Width 14″ – 18″
Seat Depth 15″ – 18″
Front Seat Height 19″ – 22″
Rear Seat Height 17″ – 20″
Back Rest Height 8″ – 20″
Back Rest Angle 90°-100°
Wheel Camber 6° standard
Warranty 5 Year
(frame only)
* See order form for full component specs.
